Technical data
| Max. drive speed | 15-30 km/h |
|---|---|
| Emission standard | Stage V |
| Fuel | Diesel |
| Engine | Kohler KDI 1903 TCR - 3 Zylinder - 1.861 ccm - Turbo Common Rail Dieselmotor |
| Power | 57 PS / 225 Nm bei 1.500 U/min kW |
| Tyres | 380/55-17 |
| Transmission | Hydrostatisch mit OneDrive-System |
| Aux. hydraulics oil flow | 84 l/min |
| Dead weight | 2.320 kg |
| Lifting height | 3,70 mm |
| Lifting capacity, max. | 2.540 kg |
| Breakout force / 50 cm | 3.000 kg |
| Pushing force (c) | 2.650 kgf |
| Average ground pressure (w/standard tires) | 932 kg/m2 |
| Turning radius: inside/outside | 1.135/2.635 mm |
| Product code | C968100 |
