Technical data

Excavator	100 - 150 t
Weight with top bracket	13000 kg
Weight without top bracket	11000 kg
Working pressure	30 - 32 MPa
Max. return pressure	0,6 MPa
Required amount of oil	500 L/min
Max. case drain pressure	0,4 MPa
Frequency	1000 1/min
Dimensions (L x W x H)	400 x 132 x 282 cm
Re-Action Power battery pressure	0,6 MPa
