Technical data

Excavator	11 - 16 t
Weight with top bracket	1700 kg
Weight without top bracket	1550 kg
Working pressure	16 - 19 MPa
Max. return pressure	0,6 MPa
Required amount of oil	120 L/min
Max. case drain pressure	0,4 MPa
Frequency	1400 1/min
Dimensions (L x W x H)	220 x 66 x 130 cm
Re-Action Power battery pressure	0,58 MPa
